S6170 Mid Torq Mid Speed Digital WP Plastic Servo

Features

70 oz.-in. torque torque at 4.5V-perfect for most 1/10 2WD vehicles
.16 sec/60 degrees provides a quick response as a steering or throttle servo
Long lead for use in bigger chassis such as some short course trucks—servo can be installed without a servo extension
Waterproof case design protects electronic components

Overview

Key Features
70 oz.-in. of torque at 4.8V is perfect for most 1/10 2WD vehicles
Long lead for use in bigger chassis such as some short course trucks—servo can be installed without a servo extension
0.16 sec/60 degrees provides a quick response as a steering or throttle servo
Waterproof case design protects electronic components
Overview
The S6170 is a good solid standard digital servo that is lightweight and offers good performance in most 1/10 2WD applications.

Specifications

Application
Surface
Bearing
Single
Bushing Or Bearing
Bearing
Gear Type
Plastic
Material
Plastic
Maximum Servo Torque
70 oz-in (5.0 kg-cm) @ 4.8V; 80 oz-in (5.8 kg-cm) @ 6.0V
Part Type
Electronics
Product Application
Surface
Programmable
No
Servo Operating Voltage
4.8 - 6.0V
Servo Size Category
Standard
Servo Type
Digital
